  • Features

    RO4000® Series

    • Lower insertion loss

    • Low PIM

    • Increased signal integrity

    • High circuit density

    • Ease of fabrication

    Low Z-axis coefficient of thermal expansion

    • MLB capability

    • Design flexibility

    Lead-free process compatible

    • High temperature processing

    • Ease of fabrication

    • Meets environmental concerns

    RT/duroid® 5870 /5880 Series High Frequency Laminates

    • Lowest electrical loss for reinforced PTFE material

    • Low moisture absorption

    • Isotropic

    • Uniform electrical properties over frequency

    • Excellent chemical resistance

  • Competence
    Layer 2-30
    The Width/Length Width:450mm , Length 900mm
    Line Width/Space Inner : 3/3mil, Outer : 3/3mil
    Minimum Drilling Diameter 0.10mm(Mechanical Dilling), 0.075-0.1mm(Laser Driling)
    Minimum Ring Width 4mil
    Board thickness 0.1-10mm
    Finished Copper Inner : 8 OZ, Outer : 10 OZ
    Spacing Between Hole And Conductor Layer≤6: 5mil, 7≤Layer≤11: 6mil, Layer≥12: 8mil
    Plate Thickness And Aperture Ratio 1:1 (Blind Via); 16:1(Through Via)
    Dimension Accuracy +/-0.10mm(specially 士0.05mm)
    Surface Processing Method ENIG、ENEPIG、 HASL、FLASH GOLD、HARD GOLD、OSP
  • Application

    • Commercial Airline Telephones

    • Microstrip and Stripline Circuits

    • Millimeter Wave Applications

    • Military Radar Systems

    • Missile Guidance Systems

    • Point to Point Digital Radio Antennas

    Industrial product

    · Industrial equipment

    · Measuring equipment

    · Power equipment

    Communication products

    ·High and multi-layer production capability

    ·Accurate impedance control

    ·Large size, thick backboard production

    ·Various special materials and mixed media

    ·Special craft: long and short gold fingers, back drill

    Medical Products

    · Obtaining long-term recognition from multiple medical clients

    · Small size, fine PCB to meet the needs of portable products

    Automotive Products

    · High reliability PCB product quality control

    · Meet the technological research and development of new energy vehicles

    · Strictly follow the IATF 16949 management system for operation
